Foam Beads Continuous EPS Pre Expander Machine With High Performance

China Foam Beads Continuous EPS Pre Expander Machine With High Performance supplier
Foam Beads Continuous EPS Pre Expander Machine With High Performance supplier Foam Beads Continuous EPS Pre Expander Machine With High Performance supplier

Large Image :  Foam Beads Continuous EPS Pre Expander Machine With High Performance

Product Details:

Place of Origin: China
Brand Name: D&T
Model Number: SPY-900II

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: USD 50000-130000 /PC
Packaging Details: wooden box
Delivery Time: 30 work days
Payment Terms: L/C, T/T, Western Union,paypal
Supply Ability: 20 SETS PER MONTH
Contact Now
Detailed Product Description
Voltage: 380V Weight: 1600kg
After-sales Service Provided: Engineers Available To Service Machinery Overseas Material Conveying Line: DN100
Power: 10kw First Expansion Density: 12~30g/l
Overall Dimension: 4700*2900*3200mm Processing Type: Foaming Machine

Foam Beads Continuous EPS Pre Expander Machine With High Performance





Characteristic:
1.Inside and outside of barrel are both made of stainless steel, and the middle layer is heat preserving material, the production efficiency is 2-3 times higher than the average machine, it can reduce 25% energy consumption.
2.The baiting system includes first time baiting device and second time baiting device.
3.This machine can process secondary pre-expansion.
4.The expanded density range of foamed beads is 7-35KG/M, the density tolerance is minimal.
5.Steam pressure reducing value is optional.

Item SPY-900 SPY-900Ⅱ
Expansion Chamber Diameter DN900 DN900
Volume 1.2m3 1.3m3
Usable Volume 0.8m3 0.8m3
Stzam Entry DN25 DN25
Consumption 200~250kg/h 200~250kg/h
Pressure 0.5~0.8mpa 0.5~0.8mpa
Compressed Air Entry DN20 DN20
Pressure 0.5~0.8mpa 0.5~0.8mpa
Drainge Entry DN20 DN20
Capacity @15g/l 250kg/h 200kg/h
@20g/l 300kg/h 250kg/h
@25g/l 350kg/h 300kg/h
@30g/l 400kg/h 350kg/h
material conveying line DN100 DN100
Connected load/power 10kw 10kw
Expand Density First Expansion 12~30g/l 12~30g/l
Secondary Expansion 7~12g/l 7~12g/l
Overall dimensions(L*W*H) 4700*2900*3200mm 4700*2900*3200mm
Weight 1600kg 1600kg

Application Of Product

.jpg

4.More Products For You To Choose

5.Certifications Of Product





Packaging & Shipping



Packing & Shipping

We have professional person for packing and we have longterm cooperation with our own

cargo agent.They could help us to send the cargo to the place all over the world with safety.For

this point,dear sir,you could believe us.

Pictures of Packing & Shipping

packing & shipping.jpg

Our Services



Our Services

1)After-sale Service:
Our engineers is avilable to oversea for coordinate installation, commissioning and training.
Cost for flight and suitable accommodation plus USD 100 per day each person will be charged additionally.
2)Lifetime maintenance free of charge.
3)Free training course at our plant.
4)24 hours on line service each day; free technical support.
5)Machine has been adjusted and test before delivery.
6)Free to design the Layout of customers' plant by our technician team.





1.Company Information

Fuyang D&T Industry CO., LTD. Specializes in manufacturing CNC foam Cutting machine,

polyurethane cutting machine, 3D Panel Machine, Concrete Sprayer and foam relation assistant

equipments. Eps Pre-expander machine.Through the research of our engineers, our cutting machine

had connected well with the popularized CAD and achieved automation and high efficiency, high

accuracy and makes iteasy to operate.We always put the customer on the first place and make utmost

efforts to satisfy you.We wholeheartedly look forward to developing economic, technical and trade

cooperation with you.

2.Our Company View

Company Information




3.Our Team

Team and customer




4.Our Exhibitions

sample display.jpg

Exhibition








FAQ



FAQ

1.Q:Are you manufacturer ?

A:Yes,We are manufacturer

2.Q: Which software do you use?

A: Dear sir,we use the CAD software

3.Q: Which way do you repair your machine

A:Our engineers is avilable to repair oversea

4.Q:Where can I find your cutting vidio?

A :Dear sir,you could find our vidio at YOUTUBE

5.Q:What is your website?

A :Dear sir,our website is www.dtfirm.com

Welcom new and old customers come and visit us!please feel free to contact us for more information!
