automatic horizontal and vertical Blade pu foam cutting machine

China automatic horizontal and vertical Blade pu foam cutting machine supplier
automatic horizontal and vertical Blade pu foam cutting machine supplier automatic horizontal and vertical Blade pu foam cutting machine supplier automatic horizontal and vertical Blade pu foam cutting machine supplier

Large Image :  automatic horizontal and vertical Blade pu foam cutting machine

Product Details:

Place of Origin: China
Brand Name: D&T
Certification: CE
Model Number: DTC-SD2012

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD35000-50000/SET
Packaging Details: packed with pvc film
Delivery Time: 20days
Payment Terms: T/T, L/C, Paypal
Supply Ability: 20 Sets Per Month
Contact Now
Detailed Product Description
Max. Product Size: 3000*2200*1250(mm) Horizontal Cutting Blade: 2300*3*0.5mm
Vertical Cutting Blade: 2300*3*0.5mm Control System: Industrial Computer+Windows XP With D&T Profiler
Cutting Speed: 0~10m/min(adjustable) Power: 10kw,380v,50hz
Blade Tension: Cylinder Tensioning 6 Bar Overall Weight: 2000kg

automatic horizontal and vertical Blade pu foam cutting machine





 automatic horizontal and vertical Blade pu foam cutting machine

1. Besides CAD software, we also design another drawing software

    by our engineers which is very easy to use. Operators only need to go

   through simple computer literacy training.


2. This CNC contour cutter is equipped with wireless remote control

    which makes the operation more humane convenient.


3. Equipped with high precision servo mechanism system;

    Rapid cutting speed and accurate cutting;

    which enhance the working efficiency.


4. 85% of dust will be collected to the bag during cutting process and low noise.


5. Operating system: Windows XP


6. Designing software: Auto CAD / Self-developed CNC operation Software.


7. Cutting software: Foam cutting control system



Technology Data:



TECHNICAL DATA
Type DTC-SL2012 DTC-SD2012
Max. Product Size 3000*2000*1200(mm) 3000*2200*1250(mm)
Horizontal Cutting Blade 2300*3*0.5mm 2300*3*0.5mm
Vertical Cutting Blade 2300*3*0.5mm 2300*3*0.5mm
Control System Industrial Computer+Windows XP with D&T Profiler Industrial Computer+Windows XP with D&T Profiler
Cutting Speed 0~10m/min(adjustable) 0~10m/min(adjustable)
Power 6kw,380v,50hz 10kw,380v,50hz
Blade Tension Cylinder Tensioning 6 Bar Cylinder Tensioning 6 Bar
Overall Weight 1800kg 2000kg
Overall Dimension 5000*3200*2400mm 5800*3180*2400mm

Packing:





For the packing, there are a professional team to loading the cargo.

and also, we have some

long-term cooperation with the shipping agent who is rich experience of carrier.

So do not worry, it can save money and safe for you.





Our Services





After-sale Service:



Our engineers is avilable to oversea for coordinate installation,

commissioning and training.

Cost for flight and suitable accommodation

plus USD 60 per day each person will be charged additionally.



2. Lifetime maintenance free of charge.



3. Free training course at our plant.



4. 24 hours on line service each day, free technical support.



5. Machine has been adjusted and test before delivery.





Warranty: 12 months limited warranty starting from date of delivery excluding wear parts.



                   shipping cost for parts to be replaced during warranty period have to be borned by the customers.





Terms of Paypent: 30% advance payment by T/T upon signing the contract



                                   70% covered by Confirmed Irrevocable Sight L/C



Company Information


Fuyang D&T Industry CO., LTD. Specializes in manufacturing CNC foam Cutting machine,

polyurethane cutting machine, quilting machine and foam relation assistant

equipments.

Through the research of our engineers, our cutting machine had connected well with

the popularized CAD and achieved automation and high efficiency,

high accuracy and makes it easy to operate.

We always put the customer on the first place and make utmost efforts to satisfy

you.We wholeheartedly look forward to developing economic,

technical and trade cooperation with you.



Products: Fast wire cutting machine, pu cutting machine,

hot wire cutting machine, eps cutting machine,

quilting machine and so on.





FAQ



1. Q:Are you a factory ?



    A:Yes,We are a manufacturer and doing the foam machines since 2006.



2. Q: Which drawing software do you use?



    A: Auto CAD.



3. Q: Whether your engineer can come to our factory for installation of the machine?



   A: Yes, sure.



4. Q: Can you import DXF files from another source?



   A : yes. Any DXF files is acceptable.



5. Q:The other fast wire machine had dust extraction and filtering. Does this machine also have dust extraction?



   A : Yes, include it.



6. Q: What countries have you sold to?



   A: Canada,Mexico,Brazil,Australia,Singapore,Malaysia,UAE,Yemen,Qatar,Algeria etc.



7. Q: What safety controls are on the machine?



    A: There are urgence bottoms on the control box and machine for accident to stop the mahicne.



     There are two fence around the cutting frame, the machine will stop when you open the fence.





 Cutting material sample

automatic horizontal and vertical Blade pu foam cutting machine
