Payment & Shipping Terms:
|Item:||CNC XPS Foam Cutting Machine||Type:||DTC-E3012|
|Product Size:||3000*1300*1300mm||Cutting Line Diameter:||0.5-1.2mm|
|Control System:||Industrial Computer||Cutting Speed:||0-1.5m/min(adjusted)|
|Weight:||1800kgs||Color:||As Cliebts Requirement|
|Name:||Eps Cutting Machine||Warranty:||1 Year|
Expander Polystyrene Hot Wire CNC Foam Cutter , EPS Panel Cutting Machine
CNC 2D EPS cutting machine/polystyrene foam cutting machine
styrofoam cutting machine/ eps block cutter/ electric hot wire eps cutter
1. Main Feature:
The main frame of the thermocol block cutting machine is welded from square profile steel,
with strong structure, high strength and no deformation.
but wires setting is done by hand.
Adopts 10KVA multi-tapped special transformer for adjustment
with wide adjustable range and multiple voltages.
Cutting speed range 0-2m/min.
2. Description Of 2D EPS cutting machine
Suit for: Polystyrene
Cutting line: Hot Wire
D&T series 2D EPS cutting machine is a special cutting machine,
which is for complex shapes of EPS products.
THis kind of cutter has one or sevaral cutting lines for different production request.
All the machines are driven by the remarkable D&T Profiler software,
which speeds up the design process and enables the operator
to obtain the best yield from the foam block.
Hot Wire Contour Cutter has perfect safe system to provide the accident.
It includes: All Motor will stop when the safety door be opened;
Exigency button on both machine and control box for accident;
brake system when cutting line broken.
3. Technical Data of 2D EPS cutting machine
|Max. Product Size||2000*1300*1000mm||3000*1300*1300(mm)||6000*1300*1300(mm)|
|Control System||Industrial Computer|
|Software||D&T Profiler||D&T Profiler||D&T Profiler|
|Power||13.5kw, 380v, 50hz||14.5kw, 380v, 50hz||14.5kw, 380v, 50hz|
