|Overall Dimension:||L4200 * W3200 * H2800 Mm||After-sales Service Provided:||Engineers Available To Service Machinery Oversea|
|Max.Foam Block:||2500×2500×1200mm||Control System:||Industrial Computer With D&T Special Profiler Software|
|Cutting Line:||3 X 0.6mm||Cutting Speed:||0~6m/min|
|Precision:||±0.5mm||Power:||8.5kw 380V 50HZ|
|Weight:||2500kg||Cutting Blade Length:||2300mm Should Comfirmed By Maker By Machine|
|Model:||DTC - S2512|
High Speed Toothed Blade Sponge Oscillating / Contour Cutter With Moving Table
The DTC - S2512 High Speed Toothed Blade Sponge Oscillating Contour Cutter is a kind of complicated shape cutter which is use for sponge.
The knife cut with very fast speed quavering, so it is high efficiency and the product is very good.
The most important is no dust during cutting
All the machines are driven by the excellent D&T Profiler software, which speeds
up the design process and enables the operator to obtain the best yield from the foam block.
Polyurethane, PU soft foam, sticky foam, latex, basotect, composite foam, frame foam, polyethylene.
* PC/ Industry computer control, easy operation.
* Worktable:plat working table, moving table (could select)
Max. Product Size
3 X 0.6mm
8.5kw 380V 50HZ
1. Q: what kind of CAD software the machine uses?
A: For the CAD software ,our machine uses 2004 or 2006(you prefer )
2. Q: about the CAD software, what's its name?
A: The name is Auto CAD Software
3. Q: where do you sell your machines mostly? which countries?
A:our main market is Russian, Middle East, Canada,USA,Austral,Mexico,Brazil for different kind types
4. Q: the operating system which you use is windows, right?
what kind of windows? XP? or Windows 7?
A:Yes ,it is Windows XP.
When operated,Our machine doesn't need to use network
We usually use XP for its stability.Also windows 7 is OK.
5. Q:is your software licensed or it's illegal? ("cracked")
A: our own profiler cutting software is develop by ourselves. It is origina
Q:but the auto-cad and the windows? the auto-cad and the windows are original too
I am asking this question because our company use only licensed software
A:windows is licensed; AutoCAD is testing type.
our machines do not include the licensed AutoCAD
if you have any drawing software, you can make the DXF file.
6. Q:the differences between our Fast Wire CNC Cutting machine and Oscillating
Blade CNC Blade cutting Machine.
A:First,Fast wire cutters use high -speed abrasive wire and Oscillating Blade cutters
use high-speed toothed blade.
Secondly,Fast wire CNC cutter is better for the rigid or half rigid foams.and for soft foam material,
the better cutter is Oscillating Blade CNC cutter.
Thirdly,fast wire CNC cutters also can cut soft material.but the dust from the soft material
needs an extra dust pelletizing system and the soft material also is not good for the fast wire
7. Q:For reputation and website:
A: for the reputation ,we are 8 years golden supplier on Alibaba.
And our engineers have researched our machine more and improved it better and better. We
promise our machine will be as good as we told. Even we keep 10% for the guarantee until to
install the machine well and the client satisfy with our machine.
