Horizontal Automatic Sponge Production Line Semi-Automatic

China Horizontal Automatic Sponge Production Line Semi-Automatic supplier
Horizontal Automatic Sponge Production Line Semi-Automatic supplier Horizontal Automatic Sponge Production Line Semi-Automatic supplier Horizontal Automatic Sponge Production Line Semi-Automatic supplier

Large Image :  Horizontal Automatic Sponge Production Line Semi-Automatic

Product Details:

Place of Origin: China
Brand Name: D&T
Model Number: DTPUF-75

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: USD35000~60000 / set
Packaging Details: packed with pvc film into 1*40HQ
Delivery Time: 45days
Payment Terms: T/T, L/C, Paypal
Supply Ability: 10 sets per month
Contact Now
Detailed Product Description
Item: Batch Box Foaming Machine Product Size: 3000*2000mm
Product Height: Below 1100mm Chemical: PPG, TDI, MC, Silicone+H2O, T9, A33, Etc.
Density: 10Kg/m³~60Kg/m³ Maximum Capacity: 220L/mould
Production Capacity: 230kg/h Total Power: 35KW
Foaming Model: Semi-automatic Application Area: Sponge, Polyurethane Foam, Mattress, Furniture

Horizontal Automatic Sponge Production Line Semi-Automatic



Product Description




      3.1 Components (total 7 components)



No.

Component

 Material Tank

Out-feed Pump

specification

1

PPG

3 Ton,A3 Steel

  CB-7

Feeding Pump, Mixing device, Constant

Temperature Coil, Material Tank Thermometer,

Liquidometer

2

TDI

2 Ton,A3 Steel

NB2-C32F

Feeding Pump, Mixing device, Constant Temperature

Coil, Material Tank Thermometer,  Liquidometer

3

MC

500L

2mm Stainless

Steel

NB2-D10F

Feeding Pump, Liquidometer

4

T9



50L

1mm Stainless

Steel

HGP-2A-F2R





5

Silicone Oil

50L

1mm Stainless

Steel

HGP-2A-F2R





6

A33



50L

1mm Stainless

Steel

HGP-2A-F2R





7

Water

50L

1mm Stainless

Steel

HGP-2A-F4R









2). Main Technology Data:



     Max.Product Size: 2400mm×2000mm (L×W)

     Max. Product Height: 1200mm

     Quantity of component of foaming material: 7 (PPG, TDI, MC, Water, Silicone oil, T9,A33)

     Density: 10Kg/m³~60Kg/m³

     Maximum capacity: 150L/mould, discontinual Foaming(two moulds), 6~10 blocks per hour

     Touch scream and semi-automatic control system with 100 foaming formula

     Power of Mixing Head: 7.5kw(Brake motor)

     Total Power: 30KW



3). Configuration





3.2 Mould

   Quantity: 2sets

   Size: W2100*L2450*H1200mm





Terms of Payment: 30% advance payment by T/T upon signing the contract

                              70% covered by T/T before delivery

Installation and Start-up:

2 technicians will be assigned to coordinate installation, commissioning and training,

cost for flight and suitable accommodation plus USD80/day will be charged additionally.



Warranty: 12 months limited warranty. Starting from date of delivery excluding wear parts.

                Shipping cost for parts to be replaced during warranty period have to be borne by the customer.



Horizontal Automatic Sponge Production Line Semi-Automatic



Horizontal Automatic Sponge Production Line Semi-Automatic
