1. Application
The oscillating foam cutting machine may process
any size foam blockall kinds of foam fontslow rebound sponges,
contoured cleaning supplies, etc.
2. Features
1. Using the control software that developed by our D&T company
can easily draw the graphics.the computer may automatically convert the graphics
into the controlling code, thus reduce your workload.
The computer can simulate the processing path to ensure the accuracy of each cutting.
the computer can optimize your nesting,
make full use of the foam, reduce the cost for you.
2. The mahine takes advantage of cutting blade vibration design,
the blade can be 360 ° rotation,
and achieves strong results automation capabilities,
this technology is the leading domestic level,
and to fill the gap in our country.
3. The difference of the machine compared
with the cutting wire machine is that it utilizes
special high-speed dual-vibration system,
the blade easy installation, simple operation and high efficiency.
4. The machine blade is importable carbon steel strip,
long service life, and to facilitate the replacement.
5. With the entire machinery safety facilities, such as
security screens,
emergency stop,
protection device of cutting wire broke ,
as well as other sensors, etc.
6. High frequency vibration,
high cutting speed, no dust.
3. Technical DaTa of CNC Memory Foam oscillating knife cutting
|
Model
|
CNC
|
|
Cutting speed(m/min)
|
0--6
|
|
Speed of cutter (m/s)
|
0--5
|
|
Cutting accuracy (mm)
|
±0.5
|
|
Blade length(mm)
|
2500
|
|
Total power(KW)
|
4
|
|
Total weight (kg)
|
2200
|
|
Size max. (mm)
|
L2500×W1200×H1200
|
|
Dimensions(mm)
|
L6000×W2550×H2500
|
4. Packing:
For the packing, there are a professional team to loading the cargo.
and also, we have some long-term cooperation with the shipping agent
who is rich experience of carrier. So do not worry,
it can save money and safe for you.
5. Company Information
Fuyang D&T Industry CO., LTD. Specializes in manufacturing
CNC foam Cutting machine,
polyurethane cutting machine,
quilting machine and
foam relation assistant equipments.
Through the research of our engineers,
our cutting machine had connected well with the popularized CAD
and achieved automation and high efficiency,
high accuracy and makes it easy to operate.
We always put the customer on the first place
and make utmost efforts to satisfy you.
We wholeheartedly look forward to developing economic,
technical and trade cooperation with you.
Products: Fast wire cutting machine,
pu cutting machine,
hot wire cutting machine,
eps cutting machine,
quilting machine and so on.
6. Samples for Cutting Product
