Horizontal 4kw 380V Oscillating Blade Cutting Machine For Sponge

1 set
MOQ
USD20000-42000/set
Price
Horizontal 4kw 380V Oscillating Blade Cutting Machine For Sponge
Features Gallery Product Description Chat Now
Features
Specifications
Color: Customizable
Max.Foam Block Size: 2500×1200×1000mm
Computer System: Industrial Computer Win7
Cutting Line: 3 X 0.6mm
Cutting Speed: <6m/min
Accuracy: ±0.5mm
Power: 4kw 380V 50HZ
Weight: 1200kg
Cutting Blade Length: 2300mm
Notes: All The Appearance And Performance Can Be Customed
Product Name: 4kw 380V Oscillating Blade Horizontal Cutting Machine For Sponge
Highlight:

4kw Oscillating Blade Cutting Machine

,

Sponge Oscillating Blade Cutter

,

Horizontal Oscillating Blade Cutting Machine

Basic Infomation
Place of Origin: China
Brand Name: D&T
Certification: CE
Model Number: DTC-S1212
Payment & Shipping Terms
Packaging Details: packaged according to the requirements of customers
Delivery Time: 30 working days
Payment Terms: T/T, L/C, Paypal
Supply Ability: 20 sets per month
Product Description

4kw 380V Oscillating Blade Horizontal cutting machine for sponge





The machine is under PC/ Industry computer control,easy to operation.  The Worktableplat working table ande moving table which could be selected.







Product Description:

1)The machine is a kind of complex shape cutter  which is suitable for flexible foam.

2)The blade cut with high speed vibrating, so that it will work faster and the product

will be smoother.

3)Specially no dust when you use Oscillating Blade Contour Cutter to cut Flexible PU.

4)All the machines are driven by the remarkable D&T Profiler software, which speeds up the design process and enables the operator to obtain the best yield from the foam block.

50Application:Polyurethane, PU soft foam, sticky foam, latex, basotect, composite foam, frame foam, polyethylene.





Specification:



Model

DTC-S1212

Control System

Industrial Computer

Max. Product Size

2500×1200×1000mm

Cutting Speed

0~6m/min

Cutting Line

3 X 0.6mm

Precision

±0.5mm

Power

4kw 380V 50HZ

Weight

1200kg



Horizontal 4kw 380V Oscillating Blade Cutting Machine For Sponge 0





Horizontal 4kw 380V Oscillating Blade Cutting Machine For Sponge 1



Horizontal 4kw 380V Oscillating Blade Cutting Machine For Sponge 2







you may care these about CAD:





Q1: What kind of CAD software does the machine use?

A1: For CAD software, our machines use 2004 or 2006 (you prefer)



Q2: What is the name of the CAD software?

A2: The name is Auto CAD Software



Q3: Where are your machines mainly sold? Which countries?

A3: Our main markets are Russia, Middle East, Canada, USA, Australia, Mexico, Brazil, for different types



Q4: The operating system you use is windows, right?

What kind of windows? experience? Or Windows 7?

A4: Yes, it is Windows XP. To operate, our machines do not need to use the network. We usually use XP because of its stability. Windows 7 works too.



Q5: Is your software licensed or illegal? ("crack")

A5: Our own contour cutting software is developed by ourselves.



Q6: The difference between our express line CNC cutting machine and swing blade CNC blade cutting machine.

A6:1) Fast wire cutting machine uses high speed abrasive wire and swing blade cutting machine uses high speed toothed blade.

2) Second, fast line CNC cutters are more suitable for rigid or semi-rigid foam. For flexible foam materials, a better tool is an oscillating blade CNC tool.

3) Third, the fast wire cutting machine can also cut soft materials. But the dust produced by soft materials requires an additional dust granulation system, and soft materials are not good for the fast wire cutting machine itself.






Cutting finish product:

  Horizontal 4kw 380V Oscillating Blade Cutting Machine For Sponge 3Horizontal 4kw 380V Oscillating Blade Cutting Machine For Sponge 4Horizontal 4kw 380V Oscillating Blade Cutting Machine For Sponge 5Horizontal 4kw 380V Oscillating Blade Cutting Machine For Sponge 6

we are 8 years golden supplier on Alibaba.And our engineers have researched our machine more and improved it better and better. Wepromise our machine will be as good as we told. Even we keep 10% for the guarantee until to



install the machine well and the client satisfy with our machine.
