Hangzhou Fuyang D&T Industry Co., Ltd.
Fuyang D&T Industry Co., Ltd. specializes in manufacturing sponge cutter, EPS cutter, PU foam cutter and CNC cutting machine.Our company takes advantage of a long experience achieved in foam industry, in a continuous technological research and in an accurate study of materials and new technology, so we can produce suitable cutting machine for you.
Place of Origin: | Zhejiang |
---|---|
Brand Name: | D&T |
Certification: | CE |
Model Number: | DTC-E2022 |
Minimum Order Quantity: | 1set |
Price: | USD20000-40000 / set |
Packaging Details: | PVC and wood package |
Delivery Time: | 30days |
Payment Terms: | T/T, L/C, Paypal |
Supply Ability: | 20 Sets Per Month |
Product Name: | DTC-E2022 3D CNC Hot Wire EPS XPS Cutter With CE Certificate | Condition: | New |
---|---|---|---|
After-sales Service Provided: | Engineers Available To Service Machine Oversea | Color: | As Your Request |
Max.Foam Block: | 2000×1300×1000mm | Control System: | Industrial Computer With D&T Special Profiler Software |
Cutting Line: | 0.25-1.2mm | Cutting Speed: | 0~6m/min |
Precision: | ±0.5mm | Power: | 13.5kw 380V 50HZ |
Weight: | 1200kg | Control System: | Industrial Computer |
Colour: | Customized | ||
Highlight: | Hot Wire Styrofoam Cutter 6m/min,Hot Wire Styrofoam Cutter CNC,6m/Min Hot Wire Foam Cutter |
Describe:
The D&T series hot wire contour cutting machine is a special cutting machine for the complex shape of EPS products. This cutting machine has one or multiple cutting lines to meet different production requirements.
All machines come with the excellent D&T Profiler software. This speeds up the design process and allows operators to get the best yield from their foam blocks.
The hot wire contour cutter has a complete safety system to prevent accidents. When the safety door opens, all motors stop and emergency buttons on the machine and control box prevent accidents.
Specification:
Model | DTC-E2012 | DTC-E3012 | DTC-E6012 |
Max Product Size | 2000*1300*1000mm | 3000*1300*1300* | 6000*1300*1300mm |
Cutting Line |
0.25-1.2mm |
0.25-1.2mm |
0.25-1.2mm |
Control System |
Industrial System |
Industrial System |
Industrial System |
Cutting Speed | 0-1.5m/min | 0-1.5m/min | 0-1.5m/min |
Power |
13.5kw 380V 50HZ |
13.5kw 380V 50HZ |
13.5kw 380V 50HZ |
Overall Weight | 1200kg | 1500kg | 2000kg |
Application:
EPS products
Software question:
1. Q: What kind of CAD software does the machine use?
A: As for CAD software, our machines use 2004 or 2006 (as you prefer)
2. Q: What is the name of your CAD software?
A: The name is Auto CAD software.
3. Q: Where do you mainly sell your machines?Which countries?
A: Our main market is Russia, Middle East, Canada, America, Australia, Mexico, Brazil, with different types
4. Q: Your operating system is Windows, right?
what kind of window? XP? or Windows 7?
A: Yes, Windows XP.
Our machine does not need to use the network when operating
I usually use XP for stability. Also Windows 7 is fine.
5. Q: Is your software licensed or illegal? ("cracked")
A: Our proprietary Profiler cutting software is proprietary. it's original
Q: But what about auto-cad and windows? Autocad and windows are also original
I am asking this question because our company only uses licensed software
A: Windows is licensed. AutoCAD is a test type.
Our machine does not contain licensed AutoCAD
If you have drawing software, you can create a DXF file.
6. Q: The difference between Fast Wire CNC Cutting Machine and Oscillating
Blade CNC blade cutting machine.
A: First, high speed wire cutter uses high speed abrasive wire and oscillating blade cutter.
Uses a high-speed serrated blade.
Second, Fast Wire CNC cutters are suitable for rigid or semi-rigid foam and flexible foam materials.
A better cutter is the oscillating blade CNC cutter.
Third, high-speed wire CNC cutters can also cut soft materials, but dust from soft materials
Requires an additional dust pelletizing system and soft materials are also not suitable for high speed wire
the cutter itself.
7. Q: About reputation and website:
A: Because of our reputation, we are his 8 years gold supplier in Alibaba.
And our engineers researched our machine further and improved it better.
Promise us that our machine will be as good as we said. Hold 10% for warranty up to
If we install the machine well, the client will be happy with our machine.
Cutting finish product:
